Laparoscopic trainers
This laparoskopic trainer is a universal device for the training of skills needed in laparoscopic surgery.


Laparoskopic trainer HELAGO
Detailed Description:

The trainer consists of laparoscopic torso with its own camera and display units with LED monitor. No additional equipment is needed to use this instrument.

Thanks to a movable camera it is possible to change a visual angle of an operating space.
One side of a trainer‘s covering dome is transparent, the other side is covered by metalic foil. This arrangement enables training in two modes

Basic mode allows absolute beginners to control training of laparoscopic instruments under the direct eye control.

In an advanced mode the control of an operation space is possible only by means of display on a screen. This mode provides a perfect simulation of a real laparoscopic operating to more advanced surgeons.

Sixteen ports on the top of the trainer enable introducing the instrument in different directions, including simulation of the single port techniques.

Using the flexible mounting system a wide range of  training objects may be fixed in the operating space of the trainer from special training devices across tissue and organ models to the actual biological specimen.


Supplied with

Specimen mounting tray, Basic suturing set, Skills set (4 tasks), Maryland forceps (2 pcs), Metzenbaum scissors and Performance ASsessment Software [PASS] (only with Professor model).


Types of Full HD Laparoscopic Trainers:

 LT016  Laparoscopic Trainer „STUDENT Full HD 1.6“ Full HD imagining on 22" LED display.
 LT017  Laparoscopic Trainer „TEACHER Full HD 1.7“ Additional HDMI otput for connection to a projector or the second display.
 LT018
Laparoscopic Trainer „PROFESSOR Full HD 1.8“
Additional USB interface, Performance ASsessment Software [PASS].

Specification of Full HD Line:

  • digital camera Full HD/1080p
  • efficient LED light source
  • Full HD LED monitor 22"
  • USB port for PC connection (only LT018 Full HD Profesor).
  • Performance assessment and video capture software (only LT018 Full HD PROFESSOR)
  • Sixteen ports - four ports for „single port laparoscopy“ simulation
  • Flexible mounting system for fixation training object



Comparison of diferent types:

   Full HD  Student 1.6  Full HD  Teacher 1.7  Full HD  Professor 1.8

 Laparoscopic torso
 yes yes  yes

 Digital camera Full HD / 1080p
 yes  yes  yes

 Stand with the display unit
 yes  yes  yes

 LED Full HD display 22"
 yes  yes  yes

 VESA display mount incl. mounting kit
 yes  yes  yes

 The main power cable to the trainer (1,8 m)  and power cable for display (0,5 m)
 yes  yes  yes

 HDMI cable to connect display unit and  display (0,5 m)
 yes  yes  yes

 Antireflection pad, Bowl for fixing training  material with 4 pcs clip
 yes  yes  yes

 Basic set for practicing surgical stitching
 yes  yes  yes

  Skills set (4 tasks)
 yes  yes  yes

  MARYLAND forceps
 yes  yes  yes

  METZENBAUM scissors
 yes  yes  yes

 Second HDMI output + HDMI cable (1,8 m)  for connect an additional display device
   yes  yes

 USB port with cable (1,8 m)
 for connect the display unit with PC
     yes

  Performance ASsessment Software [PASS]
     yes


Training station:

Each model is available as Desktop trainer with 22" LED monitor or Training station with movable stand and 23" LED monitor ('s' items).

Desktop laparoscopic trainer
Laparoscopic Training station with movable stand
Performance ASsessment Software [PASS]:

PASS is our brand new software developed in cooperation with the Technical University Brno. With PASS you may have each exercise assessed and recorded in Full HD. PASS also enables comparing recent results with parameters from previous attempts and thus follow the development of your skills. PASS is designed for multiple users.

Performance ASsessment Software
Performance ASsessment Software


Skills set (4 tasks):

Skills set (4 tasks)


Benefits:

Training Close to Reality
Besides training objects it is possible to make a training with real biological tissues, what makes the training very close to reality.


Real Tools
Real laparoscopic instruments are used during the training. This arrangement guarantees perfect skills for routine usage.

kure1              kure2             kure3
